型號
|
螺栓直徑M |
拉伸力
|
外形尺寸 |
重量
|
行程
|
||||||
(mm) |
(Inch) |
A |
B |
L1 |
L2 |
E |
F |
||||
DSHT24 |
M24 |
1" |
350 |
60 |
184 |
22 |
33 |
44 |
60 |
5.7 |
8 |
DSHT27 |
M27 |
1-1/8" |
475 |
65 |
190 |
25 |
37 |
56 |
65 |
6.5 |
10 |
DSHT30 |
M30 |
1-1/8″ |
578 |
74 |
205 |
28 |
44 |
62 |
74 |
7.1 |
10 |
DSHT33 |
M33 |
1-1/4″ |
713 |
80 |
237 |
31 |
46 |
67 |
80 |
7.3 |
10 |
DSHT36 |
M36 |
1-3/8″ |
844 |
90 |
220 |
34 |
49 |
72 |
90 |
8 |
10 |
DSHT39 |
M39 |
1-1/2″ |
1000 |
96 |
248 |
37 |
54 |
78 |
96 |
8.4 |
10 |
DSHT42 |
M42 |
1-5/8″ |
1160 |
96 |
253 |
40 |
57 |
84 |
96 |
9.1 |
10 |
DSHT45 |
M45 |
1-3/4″ |
1350 |
110 |
257 |
43 |
60 |
90 |
110 |
10.5 |
10 |
DSHT48 |
M48 |
1-7/8″ |
1525 |
118 |
261 |
45 |
62 |
95 |
118 |
11.8 |
10 |
DSHT52 |
M52 |
2″ |
1813 |
120 |
267 |
49 |
66 |
103 |
120 |
14 |
10 |
DSHT56 |
M56 |
2-1/4″ |
2094 |
131 |
290 |
53 |
70 |
107 |
131 |
16 |
10 |
DSHT60 |
M60 |
2-3/8″ |
2513 |
138 |
328 |
55 |
74 |
115 |
138 |
18 |
10 |
DSHT64 |
M64 |
2-1/2″ |
2763 |
148 |
331 |
59 |
78 |
121 |
148 |
23.5 |
10 |
DSHT68 |
M68 |
2-3/4″ |
3325 |
157 |
345 |
62 |
80 |
127 |
157 |
25 |
10 |
DSHT72 |
M72 |
2-7/8″ |
3500 |
168 |
360 |
65 |
85 |
131 |
168 |
28 |
10 |
上述為標準產品,如果其他規格,行程,更大的工作壓力或拉伸器力,請聯系當?shù)厥跈?quán)機構或我司技術工程師; |
